Place of Origin: | Shangdong Province |
---|---|
Brand Name: | MCLLROY |
Certification: | ISO/CE |
Model Number: | FD20 CPC20 CDPC20 |
Minimum Order Quantity: | 1 SET |
Price: | 4500-6500 USD |
Packaging Details: | bubble cotton,fixed fasten package |
Delivery Time: | 5-8 working day |
Supply Ability: | 300 SETS/MONTH |
Engine Model: | XinChai 490 BPG/Mitsubishi S4S/Isuzu C240 | Engine Power: | 36.8/35.3/35.4 KW |
---|---|---|---|
Rate Loading Weight: | 2000kg | Mast Stage: | 2 Normal /2 Fully Free/3 Fully Free |
Transimission: | Manual/Hydraulic Auto 1R,0,1F | Fork Length: | 920/1070/1220/1500 Mm |
Tire Type: | Air / Solid | Overhead Guard Height: | 2140 Mm |
Front Tire: | 7.00-12-12PR | Rear Tire: | 6.00-9-10PR |
Lifting Height: | 3000/4000/4500/5000/6000/6500mm | Overall Length(with/without Fork): | 3523/2453 Mm |
Overall Width: | 1160 Mm | Overall Height: | 3000mm: 4220/2060 Mm |
High Light: | Normal Combustion Forklift Truck,Fully free Combustion Forklift Truck,Mast Stage 2 Combustion Forklift Truck |
1. Products Description
MCLLROY sets the highest standards for internal combustion engine counterbalance forklift trucks with a focus on maximizing operator productivity and minimizing operational costs.
This forklift model excels in fuel efficiency, durability, and a low-maintenance design, making it a wise investment for businesses.
Equipped with standard advanced features, MCLLROY offers exceptional value for money.
These forklift trucks deliver speed, stability, and power, resulting in high efficiency, reduced emissions, and low noise levels.
Additionally, MCLLROY Forklift Trucks integrate ergonomic elements to improve comfort, control, and precision, ensuring optimal performance in diverse applications and environments.
2. Specification
Specification | FD20 |
Rate Loading Weight | 2000 KG |
Mast Stage | 2 Normal /2 Fully free/3 Fully free |
Lifting Height | 3000/4000/4500/5000/6000/6500mm |
Engine Model | XinChai 490 BPG/Mitsubishi S4S/Isuzu C240 |
Rate Power | 36.8/35.3/35.4 KW |
Transimission | Manual/Hydraulic auto 1R,0,1F |
Fork Length | 920/1070/1220/1500 mm |
Tire Type | Air / Solid |
Front Tire | 7.00-12-12PR |
Rear Tire | 6.00-9-10PR |
Overhead Guard Height | 2140 mm |
Overall Length(with/without fork) | 3523/2453 mm |
Overall Width | 1160 mm |
Overall Height (Mast extended/lowered) |
3000mm: 4220/2060 mm |
Total Weight | 2660 KG |
Front Overhang | 448 mm |
Free Fork Height | 100 mm |
Angle of Mast inclination (forward /backward) |
6°/12° |
3. Details and Advantages
Low noise level at operator's ear just 78 dBA and low vibration from power train increase comfort and reduce fatigue.
Low-noise air intake connects directly to intake filter for easy flow and quiet performance.
Fully hydro static steering is responsive, precise and effortless for the operator and requires little maintenance.
Fully hydro static steering with small and responsive steering wheel ensures precise,effortless manoeuvring.
Powerful hydraulic system offers high residual capacities for comfortable handling of heavier loads.
4. Optional Configurations
1 | Solid tires (the Advanced brand or equivalent) |
|||
2 | Automatic transmission(1-4.5Ton) | |||
3 | Sideshift | |||
4 | Thicken Toyota seat (no shock absorber) | |||
5 | Toyota seat (with shock absorber) | |||
6 | Fork positioner | |||
7 | Closed cab | |||
8 | Double front tires(1-5Ton) | |||
9 | Normal double mast:3300-4000mm. | |||
10 | Full free double mast:3000-4000mm. | |||
11 | Full free triplex mast:4500-7500mm. | |||
12 | Fork length:920/1370/1550 mm | |||
13 | Extension fork |
5. Attachment
A diverse selection of high-quality masts and attachments ensures precise compatibility and optimal configuration for various applications.
The carriage design features a single center bar, providing a large fork adjustment range that enhances functionality.
The range of available attachments includes a paper roll clamp, rotating bale clamp, load stabilizer, multi-drum clamp, bale clamp, drum clamp, dumping clamp, crane arm, string pole, sideshifter, rotating forks, fork extender, load release device, carton clamp, push-pull device, bucket, hook, and lengthened fork.
6. Explosive View Of Main Parts
No | Part No | Description | Q'ty | Remark |
1 | FD20-35-C1002 | Case,tor-con | 1 | |
2 | FD20-35-C1003 | Cup | 1 | |
3 | FD20-35-C1004 | Plug | 1 | |
4 | FD20-35-C1005 | Tor-con sets | 1 | |
5 | FD20-35-C1006 | Charging pump sets | 1 | |
6 | FD20-35-C1007 | Gasket | 1 | |
7 | FD20-35-C1008 | Snap ring | 1 | |
8 | FD20-35-C1009 | Strainer | ||
9 | FD20-35-C1010 | O-ring | 1 | |
10 | FD20-35-C1011 | Plug | 2 | |
11 | FD20-35-C1012 | O-ring | 1 | |
12 | FD20-35-C1013 | Gasket | 1 | |
13 | FD20-35-C1014 | Bolt | 1 | |
14 | FD20-35-C1015 | Bolt | 3 | |
15 | FD20-35-C1016 | Bolt | 1 | |
16 | FD20-35-C1017 | Bolt | 4 | |
17 | GB/T93-1987 | Washer | 15 | |
18 | FD20-35-C1019 | Pin | 2 | |
19 | FD20-35-C1020 | O-ring | 1 | |
20 | FD20-35-C1021 | Case,mission | 1 | |
21 | FD20-35-C1022 | Cap.bearing | 2 | |
22 | FD20-35-C1023 | Bolt | 4 | |
23 | FD20-35-C1024 | Plate,lock | 4 | |
24 | FD20-35-C1025 | Clutch,hydraulic | 1 | |
25 | FD20-35-C1026 | Shaft,idler | 1 | |
26 | FD20-35-C1027 | Bearing | 1 | |
27 | FD20-35-C1028 | Gear,kdler | 1 |
