Place of Origin: | Shangdong Province |
---|---|
Brand Name: | MCLLROY |
Certification: | ISO/CE |
Model Number: | FD25 CPC25 CDPC25 |
Minimum Order Quantity: | 1 SET |
Price: | 4500-6000 USD |
Packaging Details: | bubble cotton,fixed fasten package |
Delivery Time: | 10 days |
Supply Ability: | 100 SETS/MONTH |
Engine Power: | 36.8 / 35.3 / 35.4 KW | Loading Capacity: | 2500kg |
---|---|---|---|
Total Weight: | 3700-4000 KG | Fork Size: | 920/1070/1220/1500 Mm |
Front Tyre: | 7.00-12-12PR | Rear Tyre: | 6.00-9-10PR |
Max Working Speed: | 19 Km/h | Mast Tilt Angle: | 6°-12° |
Overhead Guard Height: | 2140 Mm | ||
Highlight: | IC Diesel Counterweight Forklift,2.5 Ton Counterweight Forklift |
1. Products Description
The well-established MCLLROY FD series 1 – 3.5t Diesel IC Counterbalance forklift integrates over 30 years of experience with the latest forklift technologies. Renowned as one of the most dependable forklifts manufactured by MCLLROY, it features a dynamic load sensing hydraulic steering system, efficient lighting, and lower fuel consumption, collectively contributing to increased productivity.
Designed to withstand a wide range of outdoor work throughout the year, including loading and unloading goods vehicles, this forklift effortlessly handles small pallets or bulk materials even in challenging environments such as wet, snowy, windy, or dirty conditions, with lift heights up to 3 meters.
Offering exceptional endurance and power at a cost-effective price point, our MCLLROY FD Series presents unparalleled value in the market.
2. Specification
Specification | FD25 |
Rate Loading Weight | 2500 KG |
Mast Stage | 2 Normal /2 Fully free/3 Fully free |
Lifting Height | 3000/4000/4500/5000/6000/6500mm |
Engine Model | XinChai 490 BPG / Mitsubishi S4S / Isuzu C240 |
Rate Power | 36.8 / 35.3 / 35.4 KW |
Transimission | Manual / Hydraulic auto 1R,0,1F |
Fork Size | 920/1070/1220/1500 mm |
Tire Type | Air / Solid |
Front Tire | 7.00-12-12PR |
Rear Tire | 6.00-9-10PR |
Overhead Guard Height | 2140 mm |
Overall Length(without fork) | 2540 mm |
Overall Width | 1160 mm |
Overall Height (Mast lowered) | 2060 mm |
Total Weight | 3700-4000 KG |
Front Overhang | 485 mm |
Free Fork Height | 100 mm |
Angle of Mast inclination (forward /backward) | 6°/12° |
Load Center | 500 mm |
Ground Clearance | 120 mm |
Wheel Base | 1600 mm |
Wheel Track | 970/970 mm |
Minimum Turning Radius | 2240 mm |
Max.Travel Speed(full loading) | 19 km/h |
Max. Lifting Speed(full Loading) | 550 mm/s |
Max. Traction Force(full loading) | 12.3 KN |
Maximum Permissible Gradient | 20 ° |
Battery | 12V/80Ah |
Working Pressure | 18.5 |
3. Details and Advantages
The front lifting cylinders have been developed with a smaller outer diameter to provide the operator with superior forward visibility. Additionally, the double lifting cylinders offer improved forward visibility. The optimized design ensures outstanding visibility in all directions.
In addition to the rubber damper between frames and the steering axle, the compound engine damper and full floating powertrain achieve a flexible connection between the frames and driving system. Consequently, traveling vibrations and vibrations from the driving system are significantly reduced.
4. Optional Configurations
1 | Solid tires (the Advanced brand or equivalent) | |||
2 | Automatic transmission(1-4.5Ton) | |||
3 | Sideshift | |||
4 | Thicken Toyota seat (no shock absorber) | |||
5 | Toyota seat (with shock absorber) | |||
6 | Fork positioner | |||
7 | Closed cab | |||
8 | Double front tires(1-5Ton) | |||
9 | Normal double mast:3300-4000mm. | |||
10 | Full free double mast:3000-4000mm. | |||
11 | Full free triplex mast:4500-7500mm. | |||
12 | Fork length:920/1370/1550 mm | |||
13 | Extension fork |
5. Attachment
We are dedicated to providing forklift VIP solution to meet all kinds of work condition which means MCLLROY forklift can be customized. For example, paper roll clamp, bale clamp, block clamp, carton clamp, double forks and so on
