Place of Origin: | Shangdong Province |
---|---|
Brand Name: | MCLLROY |
Certification: | ISO/CE |
Model Number: | FD35 CPC35 CDPC35 |
Minimum Order Quantity: | 1 SET |
Price: | 6000-7000 USD |
Packaging Details: | bubble cotton,fixed fasten package |
Delivery Time: | 5-8 working day |
Supply Ability: | 100 SETS/MONTH |
Engine Power: | 36.8/35.3/35.4 KW | Loading Capacity: | 3500kg |
---|---|---|---|
Total Weight: | 4560 KG | Fork Size: | 1220*125*45mm |
Front Tyre: | 28x9-15-12PR | Rear Tyre: | 6.50-10-10PR |
Max Working Speed: | 19km/h | Mast Tilt Angle: | 6°-12° |
Overhead Guard Height: | 2165 Mm | ||
Highlight: | 35.4KW Counterweight Forklift,3500kg Operating Weight Counterweight Forklift |
1. Products Description
The forklift truck, with a capacity 3500 kg, is part of an innovative new series that has significantly influenced the design of engine-powered trucks. Key features contributing to this innovation include the resiliently mounted mast and axle assembly, which effectively dampens vibrations within the operator's compartment.
Equipped with the highly fuel-efficient and low-maintenance Linde hydrostatic transmission, as well as the MCLLROY twin accelerator pedal system, this truck delivers exceptional performance, making it the preferred choice for handling heavy, high-value loads with precision and sensitivity. The series prioritizes operator comfort, serving as a primary motivator and fostering a seamless interface between operator and truck, resulting in unparalleled comfort, efficiency, and productivity levels. Investing in this remarkable series guarantees rapid returns, cementing its status as a sound investment.
2. Specification
Specification | FD35 |
Rate Loading Weight | 3500 KG |
Mast Stage | 2 Normal /2 Fully free/3 Fully free |
Lifting Height | 3000/4000/4500/5000/6000/6500mm |
Engine Model | XinChai 490 BPG/Mitsubishi S4S/Isuzu C240 |
Rate Power | 36.8/35.3/35.4 KW |
Transimission | Manual/Hydraulic auto 1R,0,1F |
Fork Size | 920/1070/1220/1500 mm |
Tire Type | Air / Solid |
Front Tire | 28x9-15-12PR |
Rear Tire | 6.50-10-10PR |
Overhead Guard Height | 2165 mm |
Overall Length(with/without fork) | 4065/2995 mm |
Overall Width | 1225mm |
Overall Height (Mast extended/lowered) |
3000mm : 4265/2060 mm |
Total Weight | 4560 KG |
Front Overhang | 495 mm |
Free Fork Height | 100 mm |
Angle of Mast inclination (forward /backward) |
6°/12° |
Load Center | 500 mm |
Ground Clearance | 135 mm |
Wheel Base | 1700 mm |
Wheel Track | 1000/970 mm |
Minimum Turning Radius | 2550 mm |
Max.Travel Speed(full loading) | 19 km/h |
Max. Lifting Speed(full Loading) | 480 mm/s |
Max. Traction Force(full loading) | 13.5 KN |
Maximum Permissible Gradient | 20 ° |
Battery | 12V/80Ah |
Working Pressure | 18.5 |
3. Details and Advantages
In the development of the rough terrain forklift, our consistent priority is the enhancement of comfort and ease of operation. Evidently, this is achieved through the incorporation of features such as improved vibration levels, a compound engine damper, and a full-floating seat and cabin.
The emphasis on comfort not only improves productivity but also contributes to the reduction of noise levels.
To achieve maximum productivity, it is crucial for the operator of a rough terrain forklift to experience comfort and maintain control. Our designed workplace is specifically tailored to optimize the performance of both operators and machinery.
The ergonomically optimized mast design provides exceptional visibility, ensuring maximum control and ideal driving conditions. Additionally, the sloping counterweight at the back enhances visibility during reversing maneuvers.
Furthermore, the complete suspension of the gearbox, seat, and overhead guard effectively minimizes vehicle vibrations.
The increased capacity of the optimized exhaust silencer, intake silencer, and noise shield technologies results in significantly reduced noise levels.
Lastly, the installation of pads on the steering axle effectively enhances operational comfort and reliability.
4. Configurations
1 | Solid tires (the Advanced brand or equivalent) |
|||
2 | Automatic transmission(1-4.5Ton) | |||
3 | Sideshift | |||
4 | Thicken Toyota seat (no shock absorber) | |||
5 | Toyota seat (with shock absorber) | |||
6 | Fork positioner | |||
7 | Closed cab | |||
8 | Double front tires(1-5Ton) | |||
9 | Normal double mast:3300-4000mm. | |||
10 | Full free double mast:3000-4000mm. | |||
11 | Full free triplex mast:4500-7500mm. | |||
12 | Fork length:920/1370/1550 mm | |||
13 | Extension fork |
4. Attachment
We are dedicated to providing forklift VIP solution to meet all kinds of work condition which means MCLLROY forklift can be customized. For example, paper roll clamp, bale clamp, block clamp, carton clamp, double forks and so on
/ Paper roll clamp / Rotating bale clamp / Load stabilizer / Multi-drum clamp / Bale clamp / Drum clamp / Dumping clamp / Crane arm / String Pole / Sideshifter / Rotating forks / Fork extensioner / Load release device / Carton clamp / Push-pull device / Bucket / Hook / Lengthened fork
