| Place of Origin: | China |
|---|---|
| Brand Name: | MCLLROY |
| Certification: | CE/ISO |
| Model Number: | MSL918D |
| Minimum Order Quantity: | 1 Unit |
| Price: | $4000-6000/ |
| Packaging Details: | Nude,Fasten Packing ,2 or 3 Units loaded in one 40HQ |
| Delivery Time: | 5-8 days |
| Payment Terms: | 30% T / T in advance and 70% balance before shipment / 100% L / C at sight |
| Supply Ability: | 100 Units / Month |
| Engine Mode: | Changfa 490 /Yun Nei 490 | RPM: | 2400 |
|---|---|---|---|
| Rated Power: | 42 KW | Emissions: | EU Stage II |
| Operating Weight: | 2500 Kg | Rated Load: | 800-1000 Kg |
| Bucket Capacities: | 0.5 M³ | Max. Travel Speed: | 28 Km/h |
| Gear Box: | CVT 265 Torque Converter | Axle: | Small Hub |
| Axle Base: | 2100 Mm | Brake: | Air Brake |
| Hydraulic Cycle Time - Lift: | ≤ 9 S | Min. Ground Clearance: | 230 Mm |
| Wheel Base: | 1650 Mm | Reach At Max.Dump Height: | 2900 Mm |
| Highlight: | 42kW Wheel Loader Machine,0.5m3 Bucket Wheel Loader Machine,1000kg Load Wheel Loader Machine |
||
1. Products Description
If you're looking for a small machine with bigger performances,then MCLLROY wheel loader is made for you with its amazing lifting and dumping height and huge breakout force when it is equipped with buckets,or with pallet forks,guaranteed max productivity.
We use Yunnei engine for this loader. Many developing countries do not currently have strict requirements on engine emissions. Therefore, for export to Southeast Asia, we use Yunnei engines. Yunnei engines are relatively stable in performance and affordable, and can be described as the most cost-effective engine among small loaders.
2. Specification of MCLLROY Wheel Loader
| MSL918D/ZL918D | Metric Units |
| Engine Model | Changfa 490 /Yun Nei 490 |
| RPM | 2400 |
| Rated Power | 42 kW |
| Emissions | EU Stage II |
| Operating Weight | 2500 kg |
| Rated Load | 800-1000 kg |
| Bucket Capacities | 0.5 m³ |
| Max. Travel Speed | 28 km/h |
| Gear Box | CVT 265 torque converter |
| Axle | Small hub |
| Axle Base | 2100 mm |
| Brake | Air Brake |
| Hydraulic Cycle time - lift | ≤ 9 s |
| Min. Ground Clearance | 230 mm |
| Wheel Base | 1650 mm |
| Reach at Max.Dump Height | 2900 mm |
| Dump Reach | 870 mm |
| Overall Length - With Bucket | 4700 mm |
| Overall Width | 1600 mm |
| Overall Height | 2150 mm |
| Tyre Size | 1200-16 |
| Breakout Force | 40 KN |
| Joystick | Machanical |
3.Details and advantages of MCLLROY Wheel Loader
All new cab is spacious, quiet and comfortable with all around 360° visibility to keep you productive throughout the day. Seat-mounted controls feature a multi-function joystick for lift and tilt functions with an integrated thumb operated speed range, forward/neutral/reverse (FNR) switch, trigger operated differential lock and constant flow. Optional fourth function joystick also available.
4.Certification of MCLLROY Wheel Loader
Product quality determines customer satisfaction thus the life span of a company.
MCLLROY not only acknowledged by the ISO9001:2000 international quality control system
and ISO 9001:2015 quality management system certification,but acquired the CE certificate.
MCLLROY CE certificate is for wheel loader, backhoe loader,excavator ,mixer truck .etc.
CM Issued.
