Place of Origin: | China |
---|---|
Brand Name: | MCLLROY |
Certification: | CE,ISO9001 |
Model Number: | MCL918D ZL918D |
Minimum Order Quantity: | 1 Set |
Price: | USD 3000-5000/Unit |
Packaging Details: | Nude , 3 sets in 1 40HQ |
Delivery Time: | 5-8 working days |
Supply Ability: | 100 sets / month |
Rate Power: | 42kw | Rate Load: | 800-1000kg |
---|---|---|---|
Bucket Capacity: | 0.5m³ | Max.Dump Clearance: | 2900mm |
Overall Size (L*W*H): | 4700*1600*2150mm | Operating Weight: | 2500kg |
Engine Model: | Changfa 490/ Yunnei 490 | Engine Speed/min: | 2400 Rpm |
Dump Reach: | 1000mm | Gear Box: | CVT |
Axle: | Hub | Frame: | Articulated |
Bucket Length: | 1.6m | Tire: | 1200-16 |
Highlight: | Garden 918 Wheel Loader,Agriculture 918 Wheel Loader,ZL918D Wheel Loader |
1. Products Description
MCLLROY wheel loader is wildly used in construction, agriculture ,garden,etc. And we are experiencing in making high quality efficiency productivity.Strong power and chassis help to muddy road condition,flexible turning is suitable for small space , excellent unloading height helpful for loading.
For the axle of this loader, we use cast steel small axle housing. There are iron axle and Isuzu axle on the market. The axles play a key role in loader working and walking. Especially under severe working conditions, the internal forces of the axles is large. A good axle allows users to drive safely and work with confidence.
2. Specification
Model | Metric Unit | MCL918D ZL918D |
|
Rated power | kw | 42 | |
Rated Load | kg | 800-1000 | |
Bucket Capacity | m³ | 0.5 | |
Max.Dump Clearance | mm | 2900 | |
Overall Size (L*W*H) | mm | 4700*1600*2150 | |
Operating Weight | kg | 2500 | |
Engine Model | Changfa 490/ Yunnei 490 |
||
Engine speed/min | rpm | 2400 | |
Dump Reach | mm | 1000 | |
Gear Box | CVT | ||
Axle | Hub | ||
Frame | Articulated | ||
Bucket Length | m | 1.6 | |
Tire | 1200-16 |
3. Details and Advantages
The main components of the loader are used brand-name manufacturer's products, interchangeability of good, reliable, well-resourced parts.
1) Engine:Strong driven force ,low fuel consumption ,high economic benefits.
2) Transmission:Split torque converter,not high temperature,easy to repair.
3) Axle: Heavy-duty axle ,planetary reduction ,solid and durable ,with the corresponding tires ,for the loader to provide.
4) Hydraulic system:Fully optimized layout of pipes Waterproof connectors.
4. Delivery
The most important thing for delivery is the stability. The climate at sea is unpredictable. If the reinforcement is improper, it will cause damage to the machine during transportation. For example, if the lifting boom is not properly reinforced, it will cause the boom to fall, smash the cab, and smash the glass.
The shipping process for MCLLROY is as follows:
1.Tool box put in the loader.
2.Seat and control panel warp in PVC.
3.Warning lights put in the loader.
4.Drive the loader inside the Container.
5.Stabilize the loader with heavy steel rope.
6.Fasten triangles wood in bottom of tires.
7.Close and seal the door ready for shipment.
