| Place of Origin: | China |
|---|---|
| Brand Name: | MCLLROY |
| Certification: | CE,ISO9001 |
| Model Number: | MCL932 ZL932 |
| Minimum Order Quantity: | 1 Set |
| Price: | $ 4000-6000 /Unit |
| Packaging Details: | Nude ，3 Sets Fasten Packing in 1 40HQ |
| Delivery Time: | 5-8 working days |
| Payment Terms: | 30% T / T in advance and 70% balance before shipment Or 100% L/C at sight |
| Supply Ability: | 100 sets / month |
| Type: | Front Loader | Engine Power: | 42kw |
|---|---|---|---|
| Engine Model: | YN490 Supercharged | Bucket Capacity: | 1.0m3 |
| Rated Load: | 1800kg | Dumping Height: | 3200mm |
| Condition: | New | Machine Weight: | 3500KG |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Video Technical Support,Online Support | Color: | Customize |
| Attachments: | Fork,Snow Bucket,Kinds,trencher | Dimension(long * Breadth * High): | 5500*1620*2750mm |
1. Products Description
In general, for construction machinery, the four most important factors are: price, quality, operation, and after-sales.
The amount of shovel material and the stability of the loader depend on the cooperation of the loader frame.
The flexibility and light operation mainly depends on the hydraulic system of the loader.
The low failure rate depends on quality as well as the after-sales service.
MCLLROY wheel Loaders are widely used in the construction, municipal engineering, urban and rural gardens, lime, sand, cement factories, mines and other enterprises and institutions and departments. It is particularity applied to the narrow space for the loading operation of stone,sand and other construction materials.
2. Specification
| Model | MCL932 ZL932 |
MCL936 ZL936 |
||
| Rated Load | kg | 1800 | 2000 | |
| Dipper Bucket Capacity | m³/m | 1.0/1.9m | 1.1/2.0m | |
| Max.Dump Clearance | mm | 3200 | 3500 | |
| Dump Reach | mm | 1350 | 1650 | |
| Overall Size (L*W*H) | mm | 5500*1620*2750 | 6025*2000*3000 | |
| Engine Model | YN490 | YN4100 Supercharged | ||
| Rated power | kw | 58 | 65 | |
| speed/min | rpm | 2400 | 2400 | |
| Gear Box | CVT | 280B Split Torque converter | ||
| Alex | S-hub reductro | M-hub reductro | ||
| Operating Weight | kg | 3300 | 5300 | |
| Articulated | Articulated | Articulated | ||
| Tyre Size | 20.5-16 | 1670-20 | ||
| Joystick included | Mechanical | Mechanical | ||
| Aircon | included | included | ||
| Hydraulic pilot(option) | *** | Without | ||
| running hour meter | running hour meter | running hour meter | ||
| air brake | air brake | air brake | ||
3. Details and Advantages
The main components of the loader are used brand-name manufacturer's products, interchangeability of good, reliable, well-resourced parts.
4.Production lines:
A complete production process mainly includes: material procurement-steel plate cutting-welding-spray painting -drying-assembly-inspection
Material procurement:
For the parts that can be inspected on site, our company has a dedicated quality inspector, such as whether the cylinder is leaking, these can be found out on site, and only qualified parts can be put into the warehouse; for conventional parts, the monthly defective product rate should be less than five in every 1000 parts, if it exceeds, our company sign a punishment agreement with our suppliers. If it exceeds 1%, we will pay $150 less to our supplier, if defect rate exceeds 2%, we will be deduct $300, if it exceeds 3%, we will pay $600 less, and it will double in turn.
with this agreement, suppliers will take it seriously. So in recent years, our company’s after-sales complaints have reduced, and when we offer better quality product, the reputation is getting better, and our customers' business grew with us.
Similar Model:
Cat 903D/906M/907M/908M
XCMG LW156/LW160/LW180/LW186/LW200
Liugong 816C
SDLG LG916 LG918 L918
