Place of Origin: | China |
---|---|
Brand Name: | MCLLROY |
Certification: | CE,ISO9001 |
Model Number: | MY700 |
Minimum Order Quantity: | 1 Set |
Price: | 15000-20000 USD |
Packaging Details: | Nude , 5 Sets in 1 40HQ ,2 Sets in 1 20GP |
Delivery Time: | 20-60 DAYS |
Payment Terms: | 30% T / T in advance and 70% balance before shipment / 100% L / C at sight |
Supply Ability: | 30 SETS PER MONTH |
Rated Load: | 700 Kg | Max. Working Height: | 3490 Mm |
---|---|---|---|
Rated Power: | 45 Kw | Ground Clearance: | 196 Mm |
Skip Width: | 1720 Mm | Bucket Capacities: | 0.39 M³ |
Min. Turning Radius: | 2056 Mm | Tire Model: | 10-16.5 |
Highlight: | 0.39m3 Bucket Skid Steer Loader,700kg Load Skid Steer Loader |
The MCLLROY Skid Steer loaders embody the exceptional performance and practical features that have garnered acclaim from diligent workers. These loaders are thoughtfully designed with pricing that reflects their value, presenting an impressive amalgamation of high performance, simplified options, and versatile configurations. By choosing MCLLROY equipment, you can trust in its ability to expedite tasks and deliver consistent results.
Our primary objective is to provide equipment that maximizes the potential of any given job. Whether you require strength, versatility, speed, or agility, MCLLROY equipment is meticulously designed to cater to your specific needs. With a dedicated commitment to your success, our equipment exhibits high productivity, unwavering reliability, remarkable versatility, and exceptional value.
WORK EFFICIENTLY IN UNPARALLELED COMFORT.
In addition to performance and productivity, the level of comfort offered by a machine is of utmost importance. Operators who experience comfort can remain focused on their work, leading to enhanced productivity and job satisfaction. The comfort of the machine benefits both owners and operators, and the M3-Series cab from Bobcat ranks among the best in the industry.
ENHANCED VISIBILITY
The design of the cab on Bobcat loaders prioritizes exceptional visibility from all angles.
SUPERIOR OVERHEAD VISIBILITY
A generous top window with a wide viewing area ensures optimal visibility when handling loads above the cab, such as loading trucks or stacking materials.
IMPROVED FRONT VISIBILITY
The cab-forward design positions the operating area closer to the attachment, providing operators with a better vantage point to observe their work. A single curved window offers a larger glass surface area compared to other manufacturers.
ENHANCED SIDE VISIBILITY
Operators can easily view the tracks or tires without the need to raise the loader arms, thereby improving performance in confined spaces such as grading next to a building or maneuvering onto a trailer.
EXCELLENT REAR VISIBILITY
The large rear window, combined with the angle of the back of the loader, offers a clear view behind the tailgate, ensuring enhanced situational awareness.
MY700 SIZE | MY700 main performance parameters | |||||
Item | Data | Item | Data | |||
1 | Max working height(A) | 3490mm | 1 | Loading capacity | 700KG | |
2 | Max pin height(B) | 3028mm | 2 | Weight | 2860kg | |
3 | Max height on bucket level state(C) | 2814mm | 3 | Engine | Diesel engine | |
4 | Max dumping height (D) | 2266mm | 4 | Rated speed | 2500r/min | |
5 | Max Dumping distance(F) | 437mm | 5 | Type of engine | Four cylinder, water-cooling, four-stroke | |
6 | Wheel base(G) | 1044mm | 6 | Rated power |
Xinchai 498 45KW EU II |
|
7 | Total height(H) | 1979mm | 7 | Fuel consumption rate on standard | ≦240g/KW·h | |
8 | Ground clearance(J) | 196mm | 8 | Fuel consumption rate on max torque | ≦238g/KW·h | |
9 | Overall length without bucket(K) | 2621mm | 9 | Noise | ≦117dB(A) | |
10 | Total length(L) | 3400mm | 10 | Generator power | 500W | |
11 | Skip width(M) | 1720mm | 11 | Voltage | 12V | |
12 | Total width(W) | 1665mm | 12 | Storage battery | 105AH | |
13 | Tread width to center line (P) | 1425mm | 13 | Speed | 0-10 Km/h | |
14 | Tire’s thickness N) | 240mm | 14 | Drive mode | Hydrostatic four-wheel drive | |
15 | Departure angle(α) | 19° | 15 | Tire | 10-16.5 | |
16 | Bucket dump angle(β) | 41° | 16 | Hydraulic pump flow for running | 110L/min | |
17 | Retracting angle(θ) | 18° | 17 | Hydraulic pump flow for working | 50L/min | |
18 | Turn radius(R) | 2056mm | 18 | System pressure | 15MP |
DRIVE BUSINESS EXPANSION WITH SEAMLESS INTEGRATION
To streamline operations and optimize efficiency, MCLLROY offers a wide range of over 70 attachments, including augers, breakers, and more. These attachments enable diverse tasks such as concrete breaking, demolition, and post hole digging, expanding job opportunities and maximizing the versatility of the machine. MCLLROY distinguishes itself by manufacturing a significant portion of its own attachments, ensuring smooth integration with MCLLROY loaders' electronics, hydraulics, and geometry. Attention to detail is given to factors such as visibility, as well as ease of entry and exit.
EFFICIENT ATTACHMENT CHANGES WITH QUICK COUPLERS
MCLLROY loaders are equipped with efficient quick couplers that facilitate the swift release of trapped hydraulic pressure. By simply pushing the coupler inward, hydraulic oil is effectively released through a return line back into the machine. This streamlined process ensures a clean and rapid attachment change every time.
ENHANCED CONTROL WITH ATTACHMENT CONTROL KIT
Certain attachments require precise control over multiple functions. MCLLROY provides a compact seven-pin attachment harness that enables the activation of power and fingertip control functions, eliminating the need for mechanical relays commonly used in other loaders. This fully integrated solution ensures a tidy appearance and protected routing, seamlessly integrating with your MCLLROY loader.
SWIFT AND SECURE ATTACHMENT CHANGES WITH MCLLROY SYSTEM
The MCLLROY mounting system enables quick attachment changes in under a minute, ensuring a secure fit every time. This efficient system enhances productivity and eliminates unnecessary downtime associated with attachment changes.
CONVENIENT ATTACHMENT CHANGES WITH POWER MCLLROY SYSTEM
With the Power MCLLROY system, non-hydraulic attachments can be easily changed without leaving the operator's cab. Simply align the attachment and press the switch, enabling efficient and convenient attachment changes.
HANDS-FREE HYDRAULIC CONNECTIONS WITH MCLLROY- SYSTEM
The MCLLROY attachment mounting system introduces hands-free hydraulic connections to the Power MCLLROY attachment mounting system. By aligning with the attachment's MCLLROY adapter plate and activating the Power MCLLROY switch, hydraulic connections are seamlessly established. This innovative feature enhances efficiency and is available on select models.
