Place of Origin: | China |
---|---|
Brand Name: | MCLLROY |
Certification: | CE/ISO |
Model Number: | MSL932 |
Minimum Order Quantity: | 1 Unit |
Price: | $4000-8000/ |
Packaging Details: | Nude,Fasten Packing ,2 or 3 Units loaded in one 40HQ |
Delivery Time: | 5-8 days |
Payment Terms: | 30% T / T in advance and 70% balance before shipment / 100% L / C at sight |
Supply Ability: | 100 Units / Month |
Engine Model: | Changfa 490 Supercharged /Yun Nei 490 Supercharged | RPM: | 2400 |
---|---|---|---|
Rated Power: | 60 KW | Emissions: | EU Stage II |
Operating Weight: | 3900 Kg | Load Capacities: | 1500-2000 Kg |
Bucket Capacities: | 1.0 M³ | Max. Travel Speed: | 38 Km/h |
Gear Box: | CVT 265 Torque Converter | Axle: | Small Hub Reductro |
Axle Base: | 2400 Mm | Brake: | Air Brake |
Hydraulic Cycle Time - Lift: | ≤ 8 S | Min. Ground Clearance: | 280 Mm |
Wheel Base: | 1800 Mm | Reach At Max.Dump Height: | 3300 Mm |
Dump Reach: | 750 Mm | Overall Length - With Bucket: | 5840 Mm |
Overall Width: | 1900 Mm | Overall Height: | 2820 Mm |
Tyre Size: | 20.5-16S | Joystick: | Machanical |
Min. Turning Radius: | 4500 Mm | Hour Meter: | Yes |
Tool Box: | Yes | Dual Hight&Low Speed Handle: | Yes |
Highlight: | 58kw Front Shovel Wheel Loader,Compact Front Shovel Wheel Loader |
1. Products Description of MCLLROY Wheel Loader
We need the construction machine to do heavy work, obviously it has to be efficient, take loader as an example, the bucket should shovel as much as possible, the loader should be stable while working, the control should be flexible and easy, the malfunction rate is low of course.
MCLLROY wheel Loader is a kind of front wheel loader with single bucket ,articulated and hydraulic unloading. It has been developed and designed in accordance with user requirements, reference models after absorption of domestic and overseas advanced similar structural features and advanced technology.
2. Specification of MCLLROY Wheel Loader
MSL932/ZL932 | Metric Units |
Engine Model | Changfa 490 Supercharged /Yun Nei 490 Supercharged |
RPM | 2400 |
Rated Power | 60 kW |
Emissions | EU Stage II |
Operating Weight | 3900 kg |
Load Capacities | 1500-2000 kg |
Bucket Capacities | 1.0 m³ |
Max. Travel Speed | 38 km/h |
Gear Box | CVT 265 torque converter |
Axle | Small hub reductro |
Axle Base | 2400 mm |
Brake | Air Brake |
Hydraulic Cycle time - lift | ≤ 8 s |
Min. Ground Clearance | 280 mm |
Wheel Base | 1800 mm |
Reach at Max.Dump Height | 3300 mm |
Dump Reach | 750 mm |
Overall Length - With Bucket | 5840 mm |
Overall Width | 1900 mm |
Overall Height | 2820 mm |
Tyre Size | 20.5-16S |
Joystick | Mechanical |
Min. turning radius | 4500 mm |
Hour meter | Yes |
Tool Box | Yes |
Dual Hight&Low Speed Handle | Yes |
3.Details and advantages of MCLLROY Wheel Loader
The MCLLROY MSL series wheel loader are compact, yet powerful, delivering high performance .
The turning radius is small and the steering is flexible; suitable for operating in tight spaces.
A 25% increase in lift total cycling time and a 40-45km/h travel speed will allow the operator to be more productive.
While the enhanced structure parts such as bucket link,bell crane,steering pin, tiger head lift arm basement provides the loader to be solid and durable when the loader is working under tough conditions.
4. Inspection of MCLLROY Wheel Loader
The inspection is as important as any other procedure. After checking the tire pressure,level of bucket,hydraulic oil,bolts, track width ,dashboard and electrical system , MCLLROY technicians usually need to inspect the followings(Parts III) :
1) Do the road test for 3 to 6km. If the water temperature is below 100 deg celcius after the road test, that is qualified, otherwise, technician will check where the problem is.
2) And then check if the lubricant oil pressure is normal;
3) Use thermometer to test the temperature of gearbox and hydraulic oil.
4) Touch the air pump by hand;
5) Check for abnormal noise, oil leakage.
6) Do the brake performance test :drive the loader on a 45-degree slope, step on the brake and do not let go, it's okay if the loader does not move.
