Welcome to MCLLROY！
| Place of Origin: | China |
|---|---|
| Brand Name: | MCLLROY |
| Certification: | CE,ISO9001 |
| Model Number: | MCL936 ZL936 |
| Minimum Order Quantity: | 1 Set |
| Price: | $ 4000-6000 /Unit |
| Packaging Details: | Nude ，3 Sets Fasten Packing in 1 40HQ |
| Delivery Time: | 5-8 working days |
| Payment Terms: | 30% T / T in advance and 70% balance before shipment Or 100% L/C at sight |
| Supply Ability: | 100 sets / month |
| Engine Model: | Yun Nei 4100 Supercharged | Rated Power: | 65 KW |
|---|---|---|---|
| Emissions: | EU Stage II | Rated Load: | 2000 Kg |
| Bucket Capacity: | 1.1m3 | Max.Dump Clearance: | 3500mm |
| Operating Weight: | 4880 Kg | Alex: | M-Hub Reductro |
| Axle Base: | 2220 Mm | Brake: | Air Brake |
| Hydraulic Cycle Time - Lift: | ≤ 6 S | ||
| High Light: | 65kW 2.5 Ton Wheel Loader,2.5 Ton Wheel Loader 1.1m3,2.5 Ton Heavy Machinery Loader |
||
1. Products Description
MCLLROY wheel loader is wildly used in construction, agriculture ,garden,etc. And we are experiencing in making high quality efficiency productivity.Strong power and chassis help to muddy road condition,flexible turning is suitable for small space ,excellent unloading height helpful for loading.
For the axle of this loader, we use cast steel small axle housing. There are iron axle and Isuzu axle on the market. The axles play a key role in loader working and walking. Especially under severe working conditions, the internal forces of the axles is large. A good axle allows users to drive safely and work with confidence.
2. Specification
| MCL 936 | |
| Engine Model | Yun Nei 4100 Supercharged |
| RPM | 2400 |
| Rated Power | 65 kW |
| Emissions | EU Stage II |
| Operating Weight | 4880 kg |
| Rated Load | 2500 kg |
| Bucket Capacities | 1.1 m³ |
| Max. Travel Speed | 28 km/h |
| Gear Box | CVT 280 torque converter |
| Alex | Middle hub |
| Axle Base | 2220 mm |
| Brake | Disc Brake |
| Hydraulic Cycle time - lift | ≤ 6 s |
| Min. Ground Clearance | 410 mm |
| Wheel Base | 1510 mm |
3. Details and Advantages
The main components of the loader are used brand-name manufacturer's products, interchangeability of good, reliable, well-resourced parts.
1) Engine:Strong driven force ,low fuel consumption ,high economic benefits.
2) Transmission:Split torque converter,not high temperature,easy to repair.
3) Axle: Heavy-duty axle ,planetary reduction ,solid and durable ,with the corresponding tires ,for the loader to provide.
4) Hydraulic system:Fully optimized layout of pipes Waterproof connectors.
4.Attachment
MCLLROY compact wheel loaders are wide variety of choices for many applications.On construction sites,in the recycling industry or agricultural works,with the hydraulic quick coupling and a wide range of attachments,the machine are extremely versatile.
MCLLROY wheel loader can be installed with different attachments to meet customers' work needs, as following:
Similar Model:
Cat 903D/906M/907M/908M
XCMG LW156/LW160/LW180/LW186/LW200
Liugong 816C
SDLG LG916 LG918 L918
