Heavy Duty 7.8m3 25 Ton Crawler Bulldozer With Cummins Engine

Product Details:
Place of Origin: China
Brand Name: NEW SKY
Model Number: NK230
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: USD122000-USD130000/unit
Packaging Details: no pack
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T
Supply Ability: 200units per year

Detail Information

Name: Crawler Bulldozer Operating Weight: 24840kg
Ground Pressure: 76kpa Track Gauge: 2000mm
Gradient: 30°/25° Min. Ground Clearance: 405mm
Dozing Capacity: 7.8m3 Blade Width: 3666mm
Overall Dimensions: 5733×3666×3380mm Type: Heavy Duty
High Light:

25 Ton Crawler Bulldozer

,

7.8m3 Crawler Bulldozer

,

7.8m3 heavy equipment dozer

Product Description

Heavy Duty 7.8m3 25 Ton Crawler Bulldozer With Cummins Engine



Introduction of Crawler Bulldozer



1) The NK230 Crawler Bulldozer is equipped with a new Cummins engine, a three-element torque converter, a single-lever planetary gearbox, and a semi-rigid suspension hydraulic transmission bulldozer with full hydraulic control.



2) Model integral injection instrument panel, fully sealed shock-absorbing hexahedron cab, ergonomically designed operating system is comfortable and effortless



3) The split-type tension spring box structure of the walking system is easy to maintain.



4) This machinery has the advantages of strong power, high operating efficiency, good performance and good economy.



Main specification



Operating weight

24840kg

Ground pressure

76kpa

Track gauge

2000mm

Gradient

30°/25°

Min. ground clearance

405mm

Dozing capacity

7.8 m³

Blade width

3666mm

Max. Digging depth

540mm

Overall dimensions

5733×3666×3380mm



Engine and Driving system



Engine model

Cummins NT855-C280S10

Rated revolution(rpm)

2100

Power(kw/hp)

185KW/230HP

Max.torque(N.m/rpm)

1097/1500

Torque converter

Power separating hydraulic-mechanic type

Transmission

Planetary,power shift with 4F&3R
